Honda Hornet CB600F 2003-2006 Service Repair Manual

Skip expensive dealership labor rates and take complete control of your middleweight streetfighter’s maintenance. This 2003–2006 Honda CB600F Hornet (and US-spec Honda 599) Complete Service & Repair Manual is the definitive technical handbook for owners, custom builders, and motorcycle mechanics.

Whether you are performing routine 16,000 km (10,000 mi) valve clearance checks, ultrasonic cleaning and balancing the bank of four Keihin carburetors, replacing fork seals, or troubleshooting an ignition spark issue, this digital manual delivers exact factory tolerances, exploded mechanical assemblies, and clear step-by-step instructions.

🏍️ Models & Model Years Covered

• 2003 Honda CB600F / CB600FS Hornet (Gen 2 Facelift)

• 2004 Honda CB600F Hornet / Honda 599 (US Market Release)

• 2005 Honda CB600F Hornet (Updated with 41mm Inverted USD Front Forks)

• 2006 Honda CB600F Hornet / Honda 599 (Final Carbureted Production Year)

• Covers Standard Naked (N), Cockpit Fairing (S), and European H.I.S.S.-equipped models.

What’s Included in This Service Manual?

This complete workshop manual covers every mechanical, hydraulic, and electrical system on your bike:

1. General Information & Periodic Maintenance

• Scheduled maintenance charts and inspection intervals

• Fluid capacities (engine oil, coolant, hydraulic brake fluid, fork oil)

• Spark plug heat ranges (CR9EH-9 / U27FER9) and gap settings

• Comprehensive engine and chassis fastener torque specification tables

2. 599cc DOHC 16-Valve Inline-4 Engine Overhaul

• Cylinder head disassembly, cam lobe wear limits, and camshaft timing mark alignment

• Valve clearance inspection and shim-under-bucket adjustment procedures

• Piston ring end gap, cylinder bore measurement, and connecting rod bearing tolerances

• Crankcase splitting, crankshaft journal runout, and transmission gear inspection

• Multi-plate wet clutch pack rebuilding, stack height specs, and spring free-length limits

3. Fuel System & 4-Carburetor Bank (Keihin VP)

• Bank removal, individual carburetor separation, ultrasonic cleaning, and rebuild steps

• Float height measurement and adjustment

• Idle speed setting and 4-cylinder vacuum gauge synchronization procedure

• Throttle and choke cable routing, lubrication, and free-play adjustments

4. Chassis, Wheels & Suspension

• Front Suspension: Complete teardown and seal replacement for both conventional telescopic forks (03–04) and 41mm inverted USD forks (05–06)

• Rear Suspension: Monoshock inspection, spring preload settings, and swingarm pivot bearing overhaul

• Brakes: Front dual-disc and rear single-disc Nissin caliper rebuilding, master cylinder overhaul, and bleeding procedures

• Steering head bearing inspection, adjustment, and replacement

5. Electrical System, Ignition & H.I.S.S.

• Full-color system wiring schematics with clear wire color codes

• Charging system testing (alternator stator coil resistance & regulator/rectifier output)

• Starter motor teardown, brush replacement, and starter relay diagnostics

• Electronic instrument cluster wiring, digital LCD tachometer/speedometer pinouts

• Honda Ignition Security System (H.I.S.S.) troubleshooting and immobilizer receiver checks

📋 Technical Specifications

❓ Frequently Asked Questions (FAQ)

How fast will I receive my download?

Instantly. As soon as payment is confirmed, an instant download button appears on your screen. You will also receive an automated email containing your permanent backup link for lifetime access.

Does this manual cover the USD (Inverted) fork models (2005–2006)?

Yes. It includes dedicated sections for both the conventional front forks (2003–2004) and the updated 41mm upside-down (USD) forks (2005–2006).

Can I open this manual on my smartphone or tablet in the garage?

Yes. The universal PDF format works on any smartphone (iOS/Android), tablet (iPad/Galaxy Tab), laptop, or desktop computer without requiring special reader software.

Can I print out dirty-hand pages?

Yes. You can print just the specific pages you need (such as carburetor exploded views, valve shim charts, or torque tables) so your phone or computer stays clean while you wrench.

Get Your Honda Hornet Running at Peak Power

Stop guessing on valve shim calculations, carburetor sync screws, and critical chassis torque specs. Download your complete workshop manual today and tackle your project with total confidence.
